AP70 Mk2 Autopilot Controller

SKU: 000-14958-001

The AP70 Mk2 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels.

Replacing both the AP70 and AP80 as our IMO/SOLAS autopilot controller, the AP70 Mk2 retains much of the well-reputed platform of its predecessors, but with a brilliant new display and modernised software interface.

Engineered for responsiveness, robustness and ease of use, the AP70Mk2 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, several custom-configurable work modes and multiple rudder/thruster integration.

View Key Features View Specifications
$1,980
Find a dealer

Product details

The AP70 Mk2 is a dedicated autopilot controller designed to meet the needs of professional mariners aboard a variety of commercial vessels.

Replacing both the AP70 and AP80 as our IMO/SOLAS autopilot controller, the AP70 Mk2 retains much of the well-reputed platform of its predecessors, but with a brilliant new display and modernised software interface.

The AP70 Mk2 accommodates installations with up to six drives. Previously only available with the AP80, this premium feature is now a standard in the AP70 Mk2.

Engineered for responsiveness, robustness and ease of use, the AP70Mk2 pairs a precision rotary control dial with dedicated buttons for instant access to steering modes, several custom-configurable work modes and multiple rudder/thruster integration.

Wheelmarked for use on SOLAS vessels
The AP70 Mk2 builds on, and continues the legacy of the SIMRAD Pro autopilot product portfolio. Its performance, robustness and quality are proven and recognised with the wheelmark symbol, making it suitable for all vessels ranging from small work- boats to large tankers.

Advanced configuration and tuning options to suit all ships
Parameters ranges and tuning options to support vessel dynamics. Adjustable for all weather conditions, hull types, work situations. Suitable for retro-fit on old ships as well as modern new-builds.

Compatible with all common rudder/drive types
Water jet, Azi-pods, Voith-Schneider, Rudder, outboard. Control signals to control, hydraulic pumps, solenoids, analog current/voltage, control/handshake signals.

Up to 6 rudders/thrusters integration
Dual rudders, fore and aft thrusters supports large and complex installations and redundancy.

Heavy-duty rudder feedback support
Simrad heavy-duty rudder feedbacks are supported.

Configurable Work Mode and Low/High Speed Modes
Autopilot settings can be tuned for optimal performance in separate low-speed, high-speed, and Work modes. The user-configurable Work mode allows the autopilot system to be configured for optimal response in a specific situation, such as a fully laden vessel, configurable thruster usage.

No Drift Steering
No Drift mode integrates GPS navigation with auto-steering, using position data to counteract the effects of wind and tide. This allows the AP70 Mk2 to maintain a straight track over ground on the current course, without the need to manually set a waypoint or route.

Navigation steering, route following
Navigation steering controls the ship on a pre-planned route from a Simrad MFD, Simrad ECDIS or third party MFD and ECDIS.

Command transfer and multiple control stations support
Command transfer is a mechanism useful in multi-controller installations. It enables the officer on watch to allow, deny the transfer of autopilot control to control devices such as a secondary AP70 Mk2 or a remote controller on a bridge wing station, above deck, or aft bridge depending on the work scenario. The AP70 Mk2 can also be used in an open configuration, where control flow is unrestricted.

Key Features

  • Wheelmarked for use on board SOLAS vessels (IMO, MED-B)
  • Advanced configuration and tuning options to suit all ships
  • Compatible with all common rudder/drive types
  • Up to 6 rudders/thrusters integration
  • Heavy-duty rudder feedback support
  • Configurable work modes and low/high speed modes
  • No Drift steering holds course against wind and tide
  • Navigation steering, route following
  • Command transfer and multiple control stations support

What's in the box?

  • N2K-T-RD Network T-Connector
  • N2KEXT-15RD 15ft Network Extension Cable
  • Power Cable, 4-Pin

Specifications

Display
Backlight Color
White/Red
Display Resolution
480 x 480
Viewing Angles
170° viewing angle
Physical
Compass Safe
0,4m (15,75")
Dimensions W x H x D
253 x 144 x 54mm (9,92 x 5,67 x 2,13 ")
Mounting Type
Flush, bracket
Weight
1,4 kg (3,1 lbs)
Electrical
Power Consumption max
0.7A at 12V, 0.4A at 24V
Power Consumption typical
0,7/0,4 A at 12V DC, 0,4/0,3 A at 24 V DC backlight full/off
Recommended Fuse Rating
2A
Supply Voltage
12/24VDC +30 -10%
Environment
Operating Temperature Range
-30C to +55C (-22F to +131F)
Storage Temperature Range
-25C to +70C (-13F to +158F)
Waterproofrating
Exposed IPx6
Connectivity
N2K PG Ns
See SI80 Signal Interface
NMEA 2000 Connectivity
1x CAN Micro-C port, 1 LEN
PC Connectivity
1 x Ethernet port
Autopilot
Compasssensor support
NMEA2000, NMEA0183
Engine Drive systems integration
Reversible pump, Solenoid valve on/off, Proportional valve, Analog, CAN (SG05Pro)
Manouevres Turn Patterns
U-turn, S-turn
Rudder sensor s upport
RF300, RF45X, RF25N, RF70, RF14XU
Steering Modes
Non Follow Up (NFU), Follow Up (FU), Auto, NoDrift, Nav
Approvals
Approvals Compliance
MED-B-7837-DNV, MED-B-7918-DNV, MED-D-Navigation Equipment
Type Approval
HCS, HSC, Wheelmark, US Coastguard, CCS, and RMRS approved depending on autopilot computer
Other
Interface
Keypad and rotary dial
Languages
English(US), English(UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Brazilian Portuguese, Swedish, Afrikaans, Japanese, Korean, Simplified Chinese, Traditional Chinese, Bulgarian, Hebrew, Hungarian, Slovak, Russian, Ukrainian
Warranty Period
2 years
