GO7 XSR ROW NO TRANSDUCER

Specifications

Display

[ Missing text '/product/specs/ Display Backlight Color' for ' Polish ( Poland)']

White

[ Missing text '/product/specs/ Display Resolution' for ' Polish ( Poland)']

800x480

[ Missing text '/product/specs/ Display Screen Brightness' for ' Polish ( Poland)']

1200 nits

[ Missing text '/product/specs/ Display Viewing Angles' for ' Polish ( Poland)']

80° top/bottom, 80° left/right

Physical

[ Missing text '/product/specs/ Physical Dimensions WHD' for ' Polish ( Poland)']

197 mm x 141 mm x 82.7 mm (7.56" x 5.55" x 3.26") (no bracket)

[ Missing text '/product/specs/ Physical Mounting Type' for ' Polish ( Poland)']

Bracket or Panel

[ Missing text '/product/specs/ Physical Weight' for ' Polish ( Poland)']

1.320 kg (2.91lb)

Electrical

[ Missing text '/product/specs/ Electrical Power Consumptionmax' for ' Polish ( Poland)']

20 W

[ Missing text '/product/specs/ Electrical Power Consumptiontypical' for ' Polish ( Poland)']

12 W

[ Missing text '/product/specs/ Electrical Recommended Fuse Rating' for ' Polish ( Poland)']

3A

[ Missing text '/product/specs/ Electrical Supply Voltage' for ' Polish ( Poland)']

10 - 17 V DC

Environment

[ Missing text '/product/specs/ Environment Operating Temperature Range' for ' Polish ( Poland)']

"-15°C to +55°C (5° F to 131° F)

[ Missing text '/product/specs/ Environment Shock Vibration' for ' Polish ( Poland)']

CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1

[ Missing text '/product/specs/ Environment Storage Temperature Range' for ' Polish ( Poland)']

"-20°C to +60°C (4°F to 140°F)

[ Missing text '/product/specs/ Environment Waterproofrating' for ' Polish ( Poland)']

IPX 6 and 7

Connectivity

[ Missing text '/product/specs/ Connectivity0183sentence' for ' Polish ( Poland)']

Exports NMEA0183 over WiFi

[ Missing text '/product/specs/ Connectivity Bluetooth' for ' Polish ( Poland)']

Internal

[ Missing text '/product/specs/ Connectivity Ethernet' for ' Polish ( Poland)']

1 x 5 pin yellow connector x 1 Mbit. Radar and Sirius (USA only) connectivity only (unless unlocked)

[ Missing text '/product/specs/ Connectivity Pc Connectivity' for ' Polish ( Poland)']

None

[ Missing text '/product/specs/ Connectivity Video' for ' Polish ( Poland)']

None

[ Missing text '/product/specs/ External Storage' for ' Polish ( Poland)']

1 Micro SD slot, max. 32GB each. >32 GB format to NTFS

[ Missing text '/product/specs/N2KPG Ns' for ' Polish ( Poland)']

Receive only59392 ISO Acknowledgement, 59904 ISO Request, 60928 ISO Address Claim, 65285 Temperature with Instance, 65323 Data User Group Request, 65325 Reprogram Status, 65341 Autopilot Mode, 65480 Autopilot Mode, 127245 Rudder, 127251 Rate of Turn, 127257 Attitude, 127488 Engine Parameters, Rapid Update, 127489 Engine Parameters, Dynamic, 127493 Transmission Parameters, Dynamic, 127503 AC input status, 127504 AC Output Status, 127505 Fluid Level, 127506 DC Detailed Status, 127507 Charger Status, 127508 Battery Status, 127509 Inverter Status, 129033 Time & Date, 129038 AIS Class A Position Report, 129039 AIS Class B Position Report, 129040 AIS Class B Extended Position Report, 129794 AIS Class A Static and Voyage Related Data, 129801 AIS Addressed Safety Related Message, 129802 AIS Safety Related Broadcast Message, 129808 DSC Call Information, 129809 AIS Class B “CS” Static Data Report, Part A, 129810 AIS Class B “CS” Static Data Report, Part B, 130313 Humidity, 130314 Actual Pressure, 130576 Small Craft Status, 130842 SimNet DSC Message, 130851 Event Reply, 130817 Product Info, 130820 Reprogram Status, 130832 Fuel Used - High Resolution, 130834 Engine and Tank Configuration, 130838 Fluid Level Warning, 130843 Sonar Status, Frequency and DSP Voltage,Transmit and Receive:61184 Parameter Request/Command, 65289 Trim Tab Insect Configuration, 65291 Backlight Control, 65292 Clear Fluid Level Warnings, 65293 LGC-2000 Configuration, 126208 ISO Command Group Function, 126992 System Time, 126996 Product Info, 127237 Heading/Track Control, 127250 Vessel Heading, 127258 Magnetic Variation, 128259 Speed, Water referenced, 128267 Water Depth, 128275 Distance Log, 129025 Position, Rapid Update, 129026 COG & SOG, Rapid Update, 129029 GNSS Position Data, 129283 Cross Track Error, 129284 Navigation Data, 129539 GNSS DOPs, 129540 GNSS Sats in View, 130074 Route and WP Service - WP List - WP Name & Position, 130306 Wind Data, 130310 Environmental Parameters, 130311 Environmental Parameters, 130312 Temperature, 130577 Direction Data, 130840 Data User Group Configuration, 130845 Parameter Handle, 130850 Event Command, 130831 Suzuki Engine and Storage Device Config, 130835 SetEngineAndTankConfiguration, 130839 Pressure Insect ConfigurationTransmit only65287 Configure Temperature INSOcts, 65290 Paddle Wheel Speed Configuration, 129285 Route/Waypoint Data, 130818 Reprogram Data, 130819 Request Reprogram, 130828 Set Serial Number, 130836 Fluid Level Insect Configuration, 130837 Fuel Flow Turbine Configuration

[ Missing text '/product/specs/NMEA2000 Connectivity' for ' Polish ( Poland)']

1 x NMEA 2000 Micro-C port, 1 LEN

[ Missing text '/product/specs/productdepth' for ' Polish ( Poland)']

Internal

MFD

[ Missing text '/product/specs/ Cartography Included' for ' Polish ( Poland)']

TBD

[ Missing text '/product/specs/GPS' for ' Polish ( Poland)']

Internal, 10Hz, WASS, MSAS, EGNOS

[ Missing text '/product/specs/ Internal Storage' for ' Polish ( Poland)']

90MB

[ Missing text '/product/specs/MFDAIS' for ' Polish ( Poland)']

Receive AIS data over NMEA 2000 only

[ Missing text '/product/specs/MFD Autopilot' for ' Polish ( Poland)']

Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail). Requires STBY button or Controller with STBY button to commission

[ Missing text '/product/specs/MFD Digital Switching' for ' Polish ( Poland)']

BEP C-Zone

[ Missing text '/product/specs/MFD Multimedia' for ' Polish ( Poland)']

via SonicHub2, Fusion Link, *Sirius, **JL Audio. *USA only, **AUST. & NZ only)

[ Missing text '/product/specs/ Sonar Compatibility' for ' Polish ( Poland)']

Integrated CHIRP / DownScan / ForwardScan. Single 9 Pin Xsonic Connector

[ Missing text '/product/specs/ Waypoints Routes Tracks' for ' Polish ( Poland)']

6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points.

[ Missing text '/product/specs/ Weather' for ' Polish ( Poland)']

SiriusXM via WM-3 (USA only), GRIB

GPS

[ Missing text '/product/specs/GPS Correction' for ' Polish ( Poland)']

WASS, MSAS, EGNOS, GLONASS

[ Missing text '/product/specs/GPSGPS Receiver Channels' for ' Polish ( Poland)']

32 Channels

[ Missing text '/product/specs/GPS Position Accuracy' for ' Polish ( Poland)']

Horizontal Accuracy 3 m (9.8 ft.)

[ Missing text '/product/specs/GPS Timeto First Fix' for ' Polish ( Poland)']

Cold start less than 90 seconds exposed to open sky, Satellite Reacquisition 5 sec

[ Missing text '/product/specs/GPS Updaterate' for ' Polish ( Poland)']

10 Hz

Autopilot

[ Missing text '/product/specs/ Autopilot Manouevres Turn Patterns' for ' Polish ( Poland)']

U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking

[ Missing text '/product/specs/ Autopilot Steering Modes' for ' Polish ( Poland)']

Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV. (*Boat type set to Sail)

Approvals

[ Missing text '/product/specs/ Approvals Compliance' for ' Polish ( Poland)']

CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1

Other

[ Missing text '/product/specs/ Interface' for ' Polish ( Poland)']

Touch screen, OP40 or OP50 controller via NEA 2000

[ Missing text '/product/specs/ Languages' for ' Polish ( Poland)']

Standard Language Pack: English(US), English(UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Swedish. Other Language unlocksAsian Language Pack: English (US), Japanese, Korean, Thai, Chinese, Eastern European Language Pack: English (US), English (UK), Bulgarian, German, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Lithuanian, Latvian, Polish, Slovak, TurkishRussia/Ukraine Language pack: English (US), English(UK), German, Spanish, French, Italian, Russian, UkrainianMiddle Eastern Language Pack: English (US), English (UK), Arabic, German, Spanish, Farsi, French, Italian

[ Missing text '/product/specs/ Warranty Warranty Period' for ' Polish ( Poland)']

2 Years
